Feeding Granularity: 35-50mm
Production Capacity: 0-25t/h
Application Range:Suitable to be used in ore beneficiation, coal, chemistry and other departments for sending granulous materials from stock chest to various types of material receiving devices through funnel
Pendulum feeder is a device used for transferring materials from the storage bin to receiving equipment. It is widely used in concentration, coal, chemical industry and other departments. The pendulum feeder is not suitable for delivering the dry powder or big grain material, it may result in the dust pollution and the jam of the discharging holes.
The GZD series of chute feeder is made up of the feed trough, vibration exciter, spring and bearing drive. And the vibration source is vibration exciter which is made up of two eccentric shafts including the active and passive, and the gear vice composition driven by the motor through v-belt shaft meshes the driven shaft rotation driven by the drive shaft gear in a contrary orientation in order to reach the purpose of making the materials moving stable and continuous.
|
Product Name
|
Pendulum feeder
|
Pendulum feeder
|
||
|
Product size
|
400×400
|
600×600
|
||
|
Swing times(time/min-1)
|
47
|
45.8
|
||
|
Discharge opening(mm)
|
Width
|
400
|
600
|
|
|
Height
|
400
|
600
|
||
|
Swing journey(mm)
|
0-170
|
0-220
|
||
|
Max.Feeding Size(mm)
|
35
|
50
|
||
|
Processing capacity(t/h)
|
0-12
|
3-25
|
||
|
Motor
|
Model
|
Y90S-4
|
Y100L-4
|
|
|
Power(kw)
|
1.1
|
2.2
|
||
|
Total weight(kg)
|
269
|
558
|
||
