Cement making plant
1. System equipment and the process is simple, low investment and fsctory building covers an area of less
2. High yield and low energy consumption
1. System equipment and the process is simple, low investment and fsctory building covers an area of less
2. High yield and low energy consumption
Cement making plant, also called cement rotary kiln or cement plant, is used in cement raw materials crushing plant. Our cement mill price is quite acttractive to customers.
In the cement production line, we need not only the crushing machinery, but also the cement making plant or the cement rotary kiln with the most reasonable cement mill price. The whole production process of cement plant is generally as follows: homogenizing-- preparation of raw material -- raw material homogenization -- preheat decomposition -- the burning of cement clinker -- cement grinding mill -- cement packaging. In the process flow, different cement making plants with different cement mill prices should be used.
The process of the cement making plant can be divided into two producing craftsmanship, which includes dry cement production and wet production, and that is the reason why cement plant has to be different at some level on the configuration. Portland cement production craftsmanship can be one of the most representatives in that production craftsmanship, which takes the limestone and clay as the main material and the material must be experiencing the process including cement crushing, burning and grinding in order to produce cement raw material, which can be finally turned to cement aggregate after being burned by cement rotary kiln.
| Product specification (m) |
Milling form | Transmission form | Gear box | Motor power (kw) |
Production capacity (t/h) |
Total weight (t) |
|
| Model | Speed reduction ratio | ||||||
| Φ1.83×7 | Open flow | Brim | ZD60 | 4.5 | 245 | 6.5-8 | 43.8 |
| Φ2.2×7.5 | Circle flow | Brim | ZD70 | 5 | 380 | 8-10 | 64.8 |
| Φ2.2×11 | Open flow | Central shaft | D110 | 35.5 | 630 | 12-13 | 104.6 |
| Φ2.2×13 | Open flow | Central shaft | D110 | 35.5 | 630 | 16-18 | 114 |
| Φ2.4×13 | Open flow | Central shaft | D110 | 35.5 | 800 | 20-23 | 130.6 |
| Φ2.6×13 | Open flow | Central shaft | MFY100 | 19.5 | 1000 | 28-32 | 158 |
| Φ3×9 | Circle flow | Brim | D125 | 41.2 | 1000 | 28-36.5 | 167 |
| Φ3×11 | Circle flow | Central shaft | D140 | 42.8 | 1250 | 36-47 | 180 |
| Φ3.2×13 | Open flow | Central shaft | D140 | 36.5 | 1600 | 45-50 | 225 |
| Φ3.5×13 | Circle flow | Brim | JDX1000 | 5.84 | 2000 | 60-65 | 275 |
| Φ3.8×13 | Open flow | Central shaft | MFY250 | 16.5 | 2500 | 60-62 | 320 |
| Φ4.2×13 | Open flow | Central shaft | JQS3550 | 15.6 | 3530 | 85-87 | 380 |
| Φ4.6×14 | Circle flow | Central shaft | JSI160-C | 14.6 | 4200 | 120-135 | 485 |
