Chinaware Ball Mills
Chinaware ball mill is mainly used for mixing, milling the materials. It works with less energy but produces high fineness product.
Chinaware ball mill is mainly used for mixing, milling the materials. It works with less energy but produces high fineness product.
Chinaware ball mill is mainly used for mixing, milling the materials. It works with less energy but produces high fineness product. It has two types: wet mills and dry mills. The machine can use different lining boards according to product requirement to satisfy different customer’s requirements. The milling fineness depends on the milling time. The motor is started by the coupling, which can reduce voltage and lower the starting electricity consumption. The structure is divided into integral type and freestanding type. Advantages of the machine include lower investment, energy conservancy, novel structure, easy and safe operation and stable and reliable performance.
(1).jpg)
The electro motor drives the cylinder to rotate through the reducer, and the broken ore and the steel balls inside the cylinder are brought by the lining board to a certain height under the frictional force and eccentric force produced by the rotation of the cylinder. Due to the action of gravity, the ores will drop and are gradually crushed under the impacting and grinding effect and the crushed ores will be discharged out of the cylinder through the discharging part. The discharged ores are classified by the spiral classifier, and the coarse sand will go back to ball mill from the joint feeding machine to be ground again. The feeding machine continuously and evenly feeds materials, and the ores will continuously and evenly go into the ball mill through the joint feeding machine, and the ground materials will be continuously discharged from Chinaware ball mill. For this reason, Chinaware ball mill is a powder grinding machine that can continuously work for 24 hours every day.
| Model | Feeding capacity （t/time） |
Shell rotation speed （r/min） |
Reference motor （kw） |
Liner material |
| 600×700 | 0.05 | 50 | 2.2 | Chinaware,silicon,rubber or metal（the related motor power varied as per the different liner materials and grinding materials） |
| 800×600 | 0.075 | 42 | 3 | |
| 900×1200 | 0.2 | 38.5 | 5.5 | |
| 1300×1500 | 0.5 | 33 | 7.5 | |
| 1500×1800 | 1.2 | 28.5 | 11 | |
| 1800×2000 | 1.5 | 24 | 15 | |
| 2600×2800 | 5 | 16.5 | 37 | |
| 3000×3800 | 10 | 14.5 | 57.2 | |
| 3200×4600 | 15 | 13.5 | 75 |
