High-frequency Screen

High-frequency screen consists of vibration exciter, ore slurry distributor, screen frame, machine frame, suspension springs and sieve.

Features Of High-frequency Screen

High efficiency, small amplitude and high frequency of screening; it differs from the conventional screens with breaking of the surface tension of pulp and high speed vibration on sieve cover and accelerates the separating of large-density useful mines and increases the contacting probability of the materials smaller than output granularity and the sieve pore. Therefore, it results into good condition and makes the materials smaller than the output granularity, especially the big-density materials and pulp get through the sieve pore together.

Working Principle Of High-frequency Screen

High frequency vibration fine screen is called high frequency screen for short and it is a type of classifying machine used in the ore dressing plant. The gap width of the grating of the screen is different, so that it classifies materials according to the material sizes. In the return circuit of the ore grinding process, this machine is used for the control and classification of the grinding ore product and screen out the coarse particles and the raw materials on the screen and return them to the grinding mill for re-grinding. The fine particles under the screen can be timely discharged to avoid re-grinding and over crushing. Timely screening the materials that reach the fineness requirement can improve the output of the grinding mill, reduce the energy consumption and improve the economic benefits. Installing a high frequency screen in the dressing return circuit can screen the coarse ore concentrate and send it to the grinding mill for re-grinding, and the fine particles under the screen are concentrated to improve the taste of the ore concentrate.

Technical Data
