Power: 37-45-- 630-710/kw
Capacity: 30-70 to 600-800/th
Total weight: 12 --83.21/t
Supply Ability: 20 Set/Sets per Month
Max. Feeding side length: 300-- 700/mm
Feed opening: 400×730 --1260×2040
Feature: small size, simple structure, high crushing ratio, low energy consumption, high production capacity
Hongxing Machinery has been committed to the technology innovation of impact crusher for many years by adhering to the principle that "science and technology are the primary productive forces". At present, compared with other crushers, our latest impact crusher has significantly improved in stability, durability and energy conservancy.
The impact breaker can handle materials with side length between 100 to 500 mm. Its highest compressive strength can reach 350 MPa. As for mineral impact crusher, there are so many manufacturers in the world, so it's difficult to choose the excellent manufacturer. In China, Henan Hongxing Mining Machinery Co., Ltd possesses good fame at home and abroad, and the impact crusher for sale enjoys high popularity among the customers. We believe that Hongxing Machinery will be your nice choice.
.jpg)
When the materials enter the field of the hammer, it is impacted by the hammers, thrown onto the impact plate, and crushed. The stuff springs from the impact plate, is impacted by the hammers again, and thrown onto impact plate. This process will last until the stuff meets the requirement and falls from the machine. Adjusting the distance between impact frame and rotor frame can change the shape and size of the output. When some foreign stuff enters the machine, the impact frame will fallback, the stuff falls from the machine. This device can prevent machine from damage.
| Model | Specifications (mm) |
Feed opening (mm) |
Max.feeding side length (mm) |
Capacity (t/h) |
Power (kw) |
Total weight (t) |
Dimensions ( L×W×H) (mm) |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 30-70 | 45 | 12 | 2330×1660×2300 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-90 | 55 | 15 | 2370×1700×2390 |
| PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
| PF-1214 | Φ1250×1400 | 400×1430 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
| PF-1315 | Φ1320×1500 | 860×1520 | 500 | 130-250 | 220 | 27 | 3180×2720×2620 |
| PF-1520 | Φ1500×2000 | 830×2040 | 700 | 300-550 | 400 | 50.6 | 3959×3564×3330 |
