Ore rod mill
Diameter:900 - 3200/mm
Length:1800 - 4500/mm
Shell rotation speed:18 - 38r/min
Feeding size:≤25 - ≤50/mm
Discharging size:0.833-0.147/mm
Power:18.5 - 630/kw
Total weight:5500 - 137000/kg
Diameter:900 - 3200/mm
Length:1800 - 4500/mm
Shell rotation speed:18 - 38r/min
Feeding size:≤25 - ≤50/mm
Discharging size:0.833-0.147/mm
Power:18.5 - 630/kw
Total weight:5500 - 137000/kg
There are many types of rod mills that customers can choose from, including dry rod mill, limestone rod mill and mineral rod mill. The main feature of the rod grinder lies in that during the ore grinding process, the grinding media and the rocks touch in a linear manner, so that the grinding and crushing is selective. The granularity of the final products is relatively even and the over crushing particles are few. When applied to coarse grinding, the processing capacity of the ore rod mill is higher than that of the ball mill with the same specifications.
Ore grinder also named ore grinding mill or ore rod mill is a type industrial grinding mill used for grinding ore or ore materials.
Ore grinder is an efficient tool for grinding many materials into fine powder. The ore grinding mill is used for grinding many kinds of mine and other materials, or selecting the mine. Ore grinding mill is widely used in building material, chemical industry, etc. Hongxing can manufacture ore grinder, vertical ore grinder, superfine ore grinder, coarse powder mill, rod mill and so on.
The rod mill is generally more efficient than the ball mill due to its more effective cascading action and the greater bearing surface offered by the rods. This means it can operate at lower speeds and with less grinding agents and producing less undesirable slimes byproduct. Rod mills do, however, require more attention during operation to prevent rod tangles and are generally ineffective at dry milling operations. They are also limited to a maximum rod length of approximately 20 feet (6 meters) which means they are generally smaller than ball mills. Rod mills also exhibit more liner and lifter wear than other mill types due to the comparatively high weights of the rods.
| Model |
Shell Specifications (mm)
|
Shell rotation speed (r/min) |
Feeding size (mm) |
Discharging size (mm) |
Processing capacity (t/h) |
Power (kw) |
Total weight (kg) |
|
| Diameter | Length | |||||||
| MBS0918 | 900 | 1800 | 36-38 | ≤25 | 0.833-0.147 | 0.62-3.2 | 18.5 | 5500 |
| MBS0924 | 900 | 2400 | 36 | ≤25 | 0.833-0.147 | 0.81-4.3 | 22 | 6100 |
| MBS1224 | 1200 | 2400 | 36 | ≤25 | 0.833-0.147 | 1.1-4.9 | 30 | 12000 |
| MBS1530 | 1500 | 3000 | 29.7 | ≤25 | 0.833-0.147 | 2.4-7.5 | 75 | 16800 |
| MBS1830 | 1830 | 3000 | 25.4 | ≤25 | 0.833-0.147 | 4.8-11.6 | 130 | 29000 |
| MBS2130 | 2100 | 3000 | 23.7 | ≤25 | 0.833-0.147 | 14-35 | 155 | 34800 |
| MBS2136 | 2100 | 3600 | 23.7 | ≤25 | 0.833-0.147 | 19-43 | 180 | 37000 |
| MBS2430 | 2400 | 3000 | 21 | ≤50 | 0.833-0.147 | 25-65 | 245 | 54000 |
| MBS2736 | 2700 | 3600 | 20.7 | ≤50 | 0.833-0.147 | 32-86 | 380 | 86000 |
| MBS2740 | 2700 | 4000 | 20.7 | ≤50 | 0.833-0.147 | 32-92 | 400 | 94000 |
| MBS3245 | 3200 | 4500 | 18 | ≤50 | 0.833-0.147 | 64-180 | 630 | 137000 |
