Hammer Crusher

Hammer crusher structural features:

1.The hammer of hammer crusher adopts new technology, with wear and impact resistance features.

2.According to customer requirements, adjust the size.

3.The structure seals solve the crushing plant dust pollution and dust leakage.

4.The overall design is beautiful shape, compact structure, less wearing parts, and easy maintenance, etc.,It is the upgrading products.

Hammer crusher working principle:

　　The motor of hammer crusher drives the motor in the crushing cavity make high-speed rotation. Materials from the upper are fed to the machine by the high-speed movement, blow, impact, cutting, grinding and grinding. In the lower part of the rotor, it is equipped with sieve plate, the crushed materials that are less than the sieve size will be discharged through the sieve, materials that are larger than coarse sieve retention continue to receive hammer blow and grinding, and finally are discharged out through the sieve plate from the plane.

Hammer crusher installation test:

1.To check the various system components before use accessories, and if hand wheel is in the correct position, or without loosening the fastening screws, if everything is normal, and the device is in normal operation.

2.The motor should be installed in the feed inlet in the opposite direction.

3.Check the proper lubricant of bearing;

4.According to the actual situation, you should select terrain during installation;

5.You should gently rotate the rotor by hand, whether it is normal, there is no friction phenomenon, if not, you can make running test without load, conduct a trial run for half an hour.

6.In the use process, you should check the rise of the temperature, observe the working pressure of the system at any time, in order to avoid abnormal incidents.

7.Make a detailed record of the various parts during operation, so that after the repair, you can make maintenance and failure analysis.
